• VSPLASH - NSF Highbay Luminaire

Uniquely Designed for Food Processing Applications

Venture Lighting’s VSplash LED Highbay is NSF Certified and uniquely designed for food processing applications yet maintains a high lumen efficacy. They are designed to quickly and easily upgrade existing HID and fluorescent fixtures.

High Performance LED

Easily upgrade existing H.I.D and fluorescent fixtures with this high performance LED luminaire.

Enhanced Safety

Smooth shape eliminates exposed hardware as well as prevents dust and moisture from collecting, enhancing safety for food processing applications.

Waterproof & Dust Tight

The fixture is IP69K rated which ensures the fixture is dust tight and also able to withstand cleaning by high pressure water jets.

Superior Thermal Management

The die-cast aluminum body ensures heat dissipation providing cool running operation.

Field Replaceable Optics

The 150W units are equipped with a 90 degree beam polycarbonate lens for higher mounting heights. The beam angle can be changed in field, by swapping with an accessory lens.

Corrosion Resistant

The IP69K rating makes cleaning worry free for NSF applications. Fixtures have a durable and corrosion-resistant powder coat finish.

Open Imagination
Locked Steel Gate
Locked Steel Gate
Locked Steel Gate

Stock Models

VSplash - NSF High Bay 120-277V

WattsOrder CodeInitial LumensCCTBeam Angle (°)Dimming LeadsReplace HID WattageDLC Model#NSF Certification#IES File
150WHB45236202505000K90ExternalUp to 400WHW1-150C-ABHW1-150HB45236.zip
150WHB41357202505000K90Internal (capped)Up to 400WHW1-150C-ABHW1-150hb41357.ies

VSplash - NSF High Bay 277-480V

WattsOrder CodeInitial LumensCCTBeam Angle (°)Dimming LeadsReplace HID WattageDLC Model#NSF Certification#IES File
150WHB12418202505000K90ExternalUp to 400WHW1-150C-BBHW1-150hb12418.ies
150WHB59512202505000K90Internal (capped)Up to 400WHW1-150C-BBHW1-150hb59512.ies
